AU15/17/20/23/25/28K3P
Three Phase
On Grid Inverter
Small size, light weight, support manual installation, reduce user installation and maintenance cost
Transformerless, Max. Efficiency is up to 98.7%; Euro. Efficiency is up to 98.2%; Total current THD < 2%
Active and passive, anti-islanding protection, continuously adjustable, active power (0-100%) function
CQC Gold Sun Certification, TUV Certification, SAA Certification, CE Certification
Model | AU15K3P-G5 | AU17K3P-G5 | AU20K3P-G5 | AU23K3P-G5 | AU25K3P-G5 | AU28K3P-G5 |
Input | ||||||
Max. DC input power | 19500W | 22600W | 26000W | 29900W | 32500W | 36400W |
Max. DC input voltage | 1100V | |||||
Max. DC input current | 18/30A | 30/30A | 36/30A | 36/36A | ||
MPPT voltage range | 180-1000V | |||||
Recommended MPP operating voltage | 650V | |||||
No.of MPPT | 2 | |||||
Max. no. of strings per MPPT | 1/2 | 2 | ||||
Output | ||||||
Rated output power | 15000W | 17000W | 20000W | 23000W | 25000W | 28000W |
Max. output power | 16.5kVA | 18.7kVA | 22kVA | 25.3kVA | 27.5kVA | 30.8kVA |
Max. output current | 25A | 28.3A | 32A | 36.5A | 42A | 45A |
Rated grid voltage | 400V | |||||
Grid voltage range | 310-480Vac | |||||
Rated grid frequency | 50Hz/60Hz | |||||
Grid frequency range | 45~55Hz/55~65Hz | |||||
THD | <2% (Under the rated power) | |||||
Power factor | >0.99 (Under the rated power) / Adjustable range: 0.8 leading~0.8 lagging | |||||
DC current injection | <0.5% (Under the rated power) | |||||
System data | ||||||
Max. efficiency | 98.7% | 98.8% | ||||
Euro. efficiency | 98.2% | |||||
Humidity range | 0~100%, non-condensing | |||||
Cooling type | Intelligent forced air cooling | |||||
Temperature range | -25~+60℃ | |||||
Power consumption at night | < 1W | |||||
Max. working altitude | 4000m | |||||
Display | LED indication / LCD display (Optional) | |||||
Communication interface | Wifi/RS485/GPRS | |||||
Protection | ||||||
DC reverse-polarity protection | Yes | |||||
Short circuit protection | Yes | |||||
Output over current protection | Yes | |||||
Output over voltage protection | Yes | |||||
Insulation resistance monitoring | Yes | |||||
Residual current detection | Yes | |||||
Surge protection | Yes | |||||
Grid monitoring | Yes | |||||
Islanding protection | Yes | |||||
Temperature protection | Yes | |||||
Integrated DC switch | Yes | |||||
Mechanical data | ||||||
Dimensions (WxHxD) | 427x439x212mm | |||||
Weight | 18kg | |||||
Protection class | IP66 | |||||
Standard | ||||||
Grid-connected standard | NB/T 32004-2018;IEC61727 | |||||
Safety standard | NB/T 32004-2018;IEC 62109-1/2 | |||||
Electromagnetic compatibility | IEC61000-6-2/4 |
