Single Phase
PV Compatible
0 emission PV charging
Seamless integration with PV systems
Adjustable current for optimized PV usage
Intelligent
Connectivity: Wi-Fi/Ethernet/4G/Bluetooth
Smart mobile App control
Scheduled charging
OCPP 1.6 Json(OCPP 2.0 upgradeable)
Dynamic load balancing
Flexible
Type 2 cable
Wall-mount/Floor stand installation
App operation/RFID authentication/Plug & Play
Secure & Safe
Type A+6mA DC RCD
Relay-sticking protection
| Datasheet | Model | AC7000-AE-25 | AC011K-AE-25 |
| Electrical Specification |
Power Supply | 1P+N+PE | 3P+N+PE |
| Rated Voltoge | 230V AC | 400V AC | |
| Rated Current | 32A | 16A | |
| Frequency | 50/60Hz | ||
| Rated Power | 7kW | 11kW | |
| Basic Attributes | Charge Connector | Type 2 Cable | |
| Cable Length | 4m/7m | ||
| Enclosure | PC | ||
| Installation | Wall-mount/Pole-mount(Optional) | ||
| Interactive Interface | LED Indicator | Green/Yellow/Red | |
| RFID Reader | Mifare ISO/IEC 14443 A | ||
| Start Mode | Plug&Play/RFID Card/App | ||
| Communication | Wi-Fi & Ethernet & Bluetooth | Standard | |
| 4G | Optional | ||
| OCPP | OCPP1.6 Json(OCPP 2.0 Upgradable) | ||
| Safety | RCD | 30mA Type A+6mA DC | |
| Ingress Protection | IP65 | ||
| Impact Protection | IK08 | ||
| Electrical Protection | Over current protection, Residual current protection Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over temperature protection |
||
| Certification | TUV Mark/CE/CB/RoHS/Reach | ||
| Certification Standard | EN IEC 61851-1:2019 IEC61851-1:2017 IEC61851-21-2:2021 | ||
| Warranty | 2 Years | ||
| Working Environment | Operation Temperature | -30℃ -+50℃ | |
| Work Humidity | 5%-95% | ||
| Work Altitude | <2000m | ||
| Package | Product Dimension | 328*181*87mm(H*W*D) | |
| Package Dimension | 420*280*190mm(L*W*H) | ||
| Net Weight | 3.2kg | ||
| Gross Weight | 4.0kg | ||
| External Package | Carton | ||
